Philips B Line 172B1TFL/00. Display diagonal: 43.2 cm (17"), Display resolution: 1280 x 1024 pixels, Display technology: LED, Response time: 4 ms, Native aspect ratio: 5:4, Viewing angle, horizontal: 160, Viewing angle, vertical: 140. Built-in USB hub. VESA mounting. Product colour: Black
Philips open-frame touch monitor provides optimal flexibility for mounting. A sturdy, water and dust resistant, edge-to-edge design to fit your needs. Great brightness performance and anti-glare display creates outstanding picture clarity.
| Display | |
|---|---|
| Surface hardness | 7H |
| Haze rate | 5% |
| DDC/CI | Yes |
| Display sRGB | Yes |
| Display diagonal (metric) | 43.2 cm |
| Viewable size, vertical | 27 cm |
| Viewable size, horizontal | 33.8 cm |
| Vertical scan range | 50 - 75 Hz |
| Horizontal scan range | 30 - 83 kHz |
| Pixel pitch | 0.264 x 0.264 mm |
| Pixel density | 96 ppi |
| Display number of colours | 16.78 million colours |
| Viewing angle, vertical | 140 |
| Viewing angle, horizontal | 160 |
| Dynamic contrast ratio marketing name | SmartContrast |
| Maximum refresh rate | 75 Hz |
| Contrast ratio (dynamic) | 50000000:1 |
| Contrast ratio (typical) | 1000:1 |
| Aspect ratio | 5:4 |
| Screen shape | Flat |
| Display technology | LED |
| Backlight type | W-LED |
| Response time | 4 ms |
| Display brightness | 400 cd/m |
| Touch technology | Multi-touch |
| Touchscreen technology | Projected capacitive system |
| Panel type | TN |
| Native aspect ratio | 5:4 |
| Display resolution | 1280 x 1024 pixels |
| Display diagonal | 43.2 cm (17") |
| Performance | |
|---|---|
| Low Blue Light technology | Yes |
| Flicker-free technology | Yes |
| Other operating systems supported | Android |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Component video sync | Separate sync, Sync-on-green (SOG) |
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
| Multimedia | |
|---|---|
| Built-in camera | No |
| Built-in speaker(s) | No |
| Design | |
|---|---|
| Certification | CB, CE Mark, FCC Class B, SEMKO, UKRAINIAN, ICES-003, CU-EAC, EAEU RoHS, TUV Ergo, TUV/GS, TUV Eye Comfort certified |
| Heavy metals free | Hg (mercury) |
| International Protection (IP) code | IP65 |
| Front bezel colour | Black |
| Product colour | Black |
| Ports & interfaces | |
|---|---|
| Audio output | Yes |
| DisplayPort version | 1.2 |
| DisplayPorts quantity | 1.2 |
| HDMI version | 1.4 |
| HDMI ports quantity | 1.4 |
| HDMI | Yes |
| DVI-D ports quantity | 1 |
| DVI port | Yes |
| VGA (D-Sub) ports quantity | 1 |
| USB Touch port | Yes |
| USB Type-A downstream ports quantity | 2 |
| Number of upstream ports | 1 |
| Built-in USB hub | Yes |
| Ergonomics | |
|---|---|
| LED indicators | Operation, Stand-by |
| Plug and Play | Yes |
| Palm rejection area | 30 x 30 mm |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish, Ukrainian |
| Number of OSD languages | 21 |
| On Screen Display (OSD) | Yes |
| Height adjustment | No |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Wall mountable | Yes |
| Panel mounting interface | 100 x 100 mm |
| VESA mounting | Yes |
| Power | |
|---|---|
| Power supply type | External |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (PowerSave) | 7.9 W |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (typical) | 12.1 W |
| Energy efficiency class (SDR) | E |
| Operational conditions | |
|---|---|
| Operating altitude | 0 - 3658 m |
| Non-operating altitude | 0 - 12192 m |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 C |
| Operating temperature (T-T) | 0 - 40 C |
| Sustainability | |
|---|---|
| European Product Registry for Energy Labelling (EPREL) code | 420487 |
| Doesn't contain | PVC/BFR, Mercury |
| General | |
|---|---|
| Product family | B Line |
| Weight & dimensions | |
|---|---|
| Weight (without stand) | 4.3 kg |
| Height (without stand) | 329 mm |
| Depth (without stand) | 49 mm |
| Width (without stand) | 383 mm |
| Packaging data | |
|---|---|
| Bundled software | SmartControl |
| Package weight | 5.83 kg |
| Package height | 384 mm |
| Package depth | 123 mm |
| Package width | 465 mm |
| Manual | Yes |
| Cables included | HDMI, DisplayPort, USB Type-A to USB Type-B, AC |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85285210 |
| Technical details | |
|---|---|
| Compliance certificates | RoHS |
| Other features | |
|---|---|
| Touch method | Stylus, Finger, Glove |
| Picture enhancement | SmartImage |
| Regulatory Approvals | CB; CE Mark; FCC Class B; SEMKO; UKRAINIAN; ICES-003; CU-EAC; EAEU RoHS; TUV Ergo; TUV/GS; TUV Eye Comfort certified |
| Energy efficiency class (old) | E |
| Mean time between failures (MTBF) | 70000 h |
| EasyRead mode | Yes |
| Number of simultaneous touchpoints | 10 |
| Touchscreen | Yes |
| Display viewable area (HxV) | 339.72 x 270.336 mm |
| Recyclable packaging material | 100% |
