Intel Core i5-12500, 6C (6P 0E)/12T, P-core 3.0/4.6GHz, 18MB, 1x 8GB UDIMM DDR4-3200, 256GB SSD M.2 2280 PCIe 4.0x4 Value NVMe Opal, Intel UHD Graphics 770, Windows 11 Pro
Lenovo ThinkCentre M70s Gen 3. Processor frequency: 3 GHz, Processor family: Intel Core i5, Processor model: i5-12500. Internal memory: 8 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 3200 MHz. Total storage capacity: 256 GB, Storage media: SSD, Optical drive type: DVDRW. On-board graphics card model: Intel UHD Graphics 770. Operating system installed: Windows 11 Pro, Operating system architecture: 64-bit. Power supply: 260 W. Chassis type: SFF. Product type: PC
Power & flexibility in a small form factor
The ThinkCentre M70s Gen 3 (Intel) small form factor desktop PC is engineered to save space and handle tasks like larger tower PCs can. At 8.2L, it improves productivity and employee experience with its power and convenience, while its sustainable design enhances your companys green credentials.
3-year, Onsite
| Processor |
|---|
| Bus type | DMI4 |
| Processor threads | 12 |
| Processor cache | 18 MB |
| Processor frequency | 3 GHz |
| Processor boost frequency | 4.6 GHz |
| Processor cores | 6 |
| Processor model | i5-12500 |
| Processor generation | 12th gen Intel Core i5 |
| Processor family | Intel Core i5 |
| Processor manufacturer | Intel |
| Memory |
|---|
| Memory channels | Dual-channel |
| Memory clock speed | 3200 MHz |
| Memory slots | 4x DIMM |
| Memory layout (slots x size) | 1 x 8 GB |
| Maximum internal memory | 128 GB |
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Storage |
|---|
| Compatible memory cards | SD, SDHC, SDXC |
| SSD form factor | M.2 |
| SSD interface | NVMe, PCI Express 4.0 |
| NVMe | Yes |
| SSD capacity | 256 GB |
| Number of SSDs installed | 1 |
| Total SSDs capacity | 256 GB |
| Storage media | SSD |
| Optical drive type | DVDRW |
| Total storage capacity | 256 GB |
| Card reader integrated | Yes |
| Graphics |
|---|
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card family | Intel UHD Graphics |
| On-board GPU manufacturer | Intel |
| Discrete graphics card model | Not available |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Network |
|---|
| Bluetooth | No |
| Wi-Fi | No |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Ethernet LAN | Yes |
| Ports & interfaces |
|---|
| Combo headphone/mic port | Yes |
| Line-out | Yes |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 2 |
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 4 |
| Expansion slots |
|---|
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| Design |
|---|
| Product colour | Black |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Placement supported | Horizontal/Vertical |
| Volume | 8.2 L |
| Colour name | Black |
| Chassis type | SFF |
| Performance |
|---|
| Trusted Platform Module (TPM) | Yes |
| Password protection type | HDD, Power on, Supervisor |
| Password protection | Yes |
| Number of speakers | 1 |
| Built-in speaker(s) | Yes |
| Audio system | High Definition Audio |
| Audio chip | Realtek ALC897Q-CG |
| Motherboard chipset | Intel Q670 |
| Product type | PC |
| Software |
|---|
| Operating system language | English |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Pro |
| Processor special features |
|---|
| Intel 64 | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Embedded options available | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Idle States | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Trusted Execution Technology | Yes |
| Execute Disable Bit | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Power |
|---|
| Power supply input frequency | 50 - 60 Hz |
| Power supply input voltage | 100 - 240 V |
| Power supply | 260 W |
| Operational conditions |
|---|
| Non-operating altitude | 0 - 12192 m |
| Operating altitude | 0 - 3048 m |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -40 - 60 C |
| Operating temperature (T-T) | 5 - 35 C |
| Certificates |
|---|
| Certification | EPEAT SilverENERGY STAR 8.0EPEAT GoldErP Lot 3TCO Certified 9.0RoHS compliant |
| Compliance certificates | RoHS |
| Sustainability |
|---|
| Sustainability certificates | ENERGY STAR, EPEAT Gold, EPEAT Silver, ErP, TCO |
| Weight & dimensions |
|---|
| Weight | 5.3 kg |
| Height | 340 mm |
| Depth | 298 mm |
| Width | 93 mm |
| Packaging content |
|---|
| Keyboard included | Yes |
| Mouse included | Yes |
| Display included | No |
| General |
|---|
| Product family | ThinkCentre |
| Product series | M |
| Other features |
|---|
| Harmonized System (HS) code | 84715000 |
