iiyama ProLite T2453MIS-B1 23.6" Full HD Monitor - 4ms, VA, Speakers, Black
iiyama ProLite T2453MIS-B1. Display diagonal: 59.9 cm (23.6"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 4 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178, Viewing angle, vertical: 178. Built-in speaker(s). Built-in USB hub. VESA mounting. Product colour: Black
24" 10 point Touch monitor based on IR Touch technology
The ProLite T2453MIS-B1 is based on IR touch technology (10 touch points) with a pure-glass scratch resistive front, offering superior image clarity and screen durability. The screen can be touched with a soft stylus, finger or gloved hand making it suitable for several applications. The VA panel technology guarantees high performance with excellent colour reproduction and high contrast, making it an excellent choice for a vast array of demanding interactive applications. A solid and steady base supports the touchscreen with an adjustable stand. Multiple inputs (VGA, HDMI, DP) are available for flexible connectivity along with USB for the touch interface.
OVERDRIVE ON / OFF
When very fast graphics are displayed your monitor can sometimes get blurry. Turning on the OverDrive feature will eliminate that.
| Display |
|---|
| Surface hardness | 7H |
| Display diagonal (metric) | 59.8 cm |
| Horizontal scan range | 30 - 80 kHz |
| Pixel pitch | 0.272 x 0.272 mm |
| Display number of colours | 16.78 million colours |
| Viewing angle, vertical | 178 |
| Viewing angle, horizontal | 178 |
| Contrast ratio (dynamic) | 12000000:1 |
| Contrast ratio (typical) | 3000:1 |
| Screen shape | Flat |
| Display technology | LED |
| HD type | Full HD |
| Response time | 4 ms |
| Display brightness | 250 cd/m |
| Touch technology | Multi-touch |
| Touchscreen technology | Infrared |
| Panel type | VA |
| Native aspect ratio | 16:9 |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 59.9 cm (23.6") |
| Performance |
|---|
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
| Multimedia |
|---|
| Built-in microphone | No |
| RMS rated power | 4 W |
| Number of speakers | 2 |
| Built-in camera | No |
| Built-in speaker(s) | Yes |
| Design |
|---|
| Certification | CE, EAC, RoHS, ErP, WEEE, VCCI, REACH, UKCA |
| Glass thickness | 1 mm |
| Product colour | Black |
| Ports & interfaces |
|---|
| HDCP | Yes |
| Headphone outputs | 1 |
| Headphone out | Yes |
| DisplayPorts quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI | Yes |
| VGA (D-Sub) ports quantity | 1 |
| USB Touch port | Yes |
| USB Type-A downstream ports quantity | 1 |
| Number of upstream ports | 1 |
| Built-in USB hub | Yes |
| Ergonomics |
|---|
| Plug and Play | Yes |
| Tilt adjustment | Yes |
| Tilt angle range | -25 - 95 |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Wall mountable | Yes |
| Panel mounting interface | 100 x 100 mm |
| VESA mounting | Yes |
| Power |
|---|
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (off) | 0.3 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (typical) | 18 W |
| Energy consumption (SDR) per 1000 hours | 14 kWh |
| Energy efficiency class (SDR) | D |
| Sustainability |
|---|
| European Product Registry for Energy Labelling (EPREL) code | 1085889 |
| General |
|---|
| Product family | ProLite |
| Weight & dimensions |
|---|
| Weight (with stand) | 6 kg |
| Height (with stand) | 391 mm |
| Depth (with stand) | 220.5 mm |
| Width (with stand) | 571 mm |
| Packaging data |
|---|
| Package height | 490 mm |
| Package depth | 190 mm |
| Package width | 645 mm |
| Logistics data |
|---|
| Harmonized System (HS) code | 85285210 |
| Other features |
|---|
| Number of simultaneous touchpoints | 10 |
| Touchscreen type | Multi-user |
| Touchscreen | Yes |
| Display viewable area (HxV) | 521.3 x 293.2 mm |
